Meccano Cargo Ship

This CAD model is my modified version of a Meccano Cargo Ship (Model No. 10.4) from 1973. It’s based on a typical high-capacity general cargo vessel, likely of the type built in Great Britain during the 1950s or 60s.

In the early 1900s, and for a brief period following the end of World War II, the United Kingdom was the largest shipbuilder in the world, relying heavily on unionized skilled labour and inexpensive manual construction methods to maintain their competitive advantage. However, pressures from foreign competition and the reluctance of UK shipbuilders to adopt modern and faster shipbuilding technologies led to a dramatic decline in their dominance of the industry, starting in the late 1950s. By 2024, the UK’s commercial shipbuilding output had fallen to just 0.01% of the world’s total production. This article is an interesting read on the history of the UK’s shipbuilding industry, and this YouTube video by Animagraffs is an excellent computer animation showing the inner workings of a typical combined passenger-cargo ship from the early 1900s.

The model includes three cargo holds, derricks, lifeboats, and other details. My version includes a few features in addition to those described in the instruction manual, including floors and walls for the cargo holds, bridge, and superstructure; handrailing at the bow and stern; hooks, pulley blocks, and winches for two of the derricks; and a chain locker for the anchor chain. The actual model is about 7.5 feet (2.3 m) long.
